Quality assurance

The quality of plating technologies we have newly created in the nano- and micro-worlds is proven and guaranteed by experienced staff who make full use of advanced inspection equipment and evaluation devices. Here, we introduce our "analyzation/observation equipment," "solution analyzers," "evaluation devices," and other equipment.

* For devices and equipment with a link, see photos by clicking their names.
Okayama Factory
Treatment/observation equipment

Equipment name Manufacturer Model Quantity
FE-SEM/EDX
(field-emission scanning electron microscope/energy dispersive X-ray microanalyzer)
Hitachi High-Technologies Corporation/Horiba, Ltd. S-4800/EX-350 1
FIB (focused ion beam system) Hitachi High-Technologies Corporation FB-2100 1
Microscope Keyence Corporation VHX-5000 1
Color 3D laser microscope Keyence Corporation VK-9700 1
Measuring microscope Nikon Corporation MM-11 1

Stereo microscope

Leica Microsystems GmbH

S8AP0 1
CP (cross Section Polisher)

JEOL Ltd.

SM09010 1

Ion sputter

Hitachi High-Technologies Corporation

E-1010 1

Microtome

Leica Microsystems GmbH

RM2265 1

Precision cut-off machine

Marumoto Struers K.K.

Auccutom-50 1

Grinding machine

Marumoto Struers K.K. TegraPol-11 1

Vacuum impregnation unit

Marumoto Struers K.K. Epovac 1

Measuring equipment

Equipment name Manufacturer Model Quantity

Autograph

Shimadzu Corporation AGS-X 1
Electrical contact simulator Yamasaki Seiki Kenkyusho Inc. CRS-1 1
Loresta resistivity meter Mitsubishi Chemical Analytech Co., Ltd. MCP-T700 1
Nano particle size analyzer Shimadzu Corporation SALD-7100 1
Fine shape measuring machine Kosaka Laboratory Ltd. ET200 1
X-ray fluorescence coating thickness gauge Hitachi High-Technologies Corporation SFT9300 1
X-ray fluorescence coating thickness gauge Hitachi High-Technologies Corporation SFT9500 1
X-ray fluorescence coating thickness measuring instrument Fischer Instruments K.K. XDLM 1
Micro Vickers hardness testing machine Mitsutoyo Corporation HM-124 1
Surface roughness tester Mitsutoyo Corporation SJ-301 1
Gloss meter Nippon Denshoku Industries Co., Ltd. ND-11 1
Solder checker Rhesca Corporation SAT-5200 1
Solder wettability testing apparatu Japan Unix Co., Ltd. UF-701D 1
ICP emission spectrometer Shimadzu Corporation ICPS-7510 1
Atomic absorption spectrometer Hitachi High-Technologies Corporation Z-5310 1
Ultraviolet absorptiometer Shimadzu Corporation UV-1600PC 1
Capillary electrophoresis system Otsuka Electronics Co., Ltd. G-7100A 1
CVS (cyclic voltammetric stripping) Metrohm AG 894 1

Environmental test equipment

Equipment name Manufacturer Model Quantity
Mixed flowing gas corrosion test cabinet Yamasaki Seiki Kenkyusho Inc. GLP-91 1
Salt spray test instrument Suga Test Instruments Co., Ltd. CAP-90 1
Highly accelerated life testing device Espec Corp. EHS-411M 1
Thermal shock chamber Hitachi Appliances, Inc. ES-56L 1
Constant climate cabinet Espec Corp. PH-1KT 1
Elevator-hearth muffle furnace Marusho Denki Co., Ltd. MNCDQ0043 1




Tochigi Factory
Treatment/observation equipment
Equipment name Manufacturer Model Quantity
SEM/EDX/EBSD
(scanning electron microscope/energy dispersive X-ray microanalyzer/backscattered electron diffraction pattern)
Hitachi High-Technologies Corporation/Horiba, Ltd./TSL Solutions Ltd. S-3000H/EX-250/OIM 1
Microscope Keyence Corporatio VHX-900 1
Wet precision cut-off machine Refine Tec Ltd. R00-971 1

Measuring equipment

Equipment name Manufacturer Model Quantity
X-ray fluorescence coating thickness gauge Hitachi High-Technologies Corporation SFT9300 1
Micro Vickers hardness testing machine Mitsutoyo Corporation HM-220A 1
Solder checker Rhesca Corporation SAT-5200 1
Atomic absorption spectrometer Hitachi High-Technologies Corporation ZA3000 1
Ultraviolet absorptiometer Shimadzu Corporation UV-1600PC 1
